LED wall
- The current size of the wall in the photos is 10×5 meters
- From January 2025 we offer a new size of 12 x 5 meters
- From February 12, 2025 we offer a new dimension of 16 x 5 meters, two sliding panels 3×2 m, ceiling 20 m2
- We are extending the studio by a total of 5 metres (!)
- The LED wall will of course also include “tracking” and the “unreal” offer
- The 0.5×0.5m LED screen offers very fine resolution, it is designed for indoor-outdoor use.
- The pixel pitch is 2.6 mm, the wall offers a large viewing angle of up to 140°, low viewing distance (3m)
- The LED wall has a high quality image with a high contrast ratio for significant black depth and colour fidelity – 10bit depth
- Angle adjustment +/- 5°
- This LED wall has been used to film shows such as Foundation (Apple TV) and other shows and movies such as StarWars Mandalorian, Avengers Endgame, Dune, Tenet, Dr. Strange …
- The wall is under constant service
LED WALL (one colour, graphics) + LIGHT PARK + TECHNOLOGY without limitations | day/Kč |
---|---|
1. Commercials, commercial programs, presentations, foreign productions | 69900 |
2. Non-commercial programmes | 59900 |
3. Artistic creation | 49900 |
4. Short-term rental for 1.hour including lights, equipment, energy and technology: 10.000,-Kč (each additional hour 5.000,-Kč) *** |
LED WALL (CEILING + SIDES) + LIGHT PARK + TECHNOLOGY without limitations | day/Kč |
---|---|
1. Commercials, commercial programs, presentations, foreign productions | 149900 |
2. Non-commercial programmes | 129900 |
3. Artistic creation | 99900 |
4. Short-term rental for 1.hour including lights, equipment, energy and technology: 26.000,-Kč (each additional hour 13.000,-Kč) *** |
LED WALL (CEILING + SIDES) + VIDEO TRACKING + LIGHT PARK + TECHNOLOGY without limitations | day/Kč |
---|---|
1. Commercials, commercial programs, presentations, foreign productions | 199900 |
2. Non-commercial programmes | 149900 |
3. Artistic creation | 129900 |
4. Short-term rental for 1.hour including lights, equipment, energy and technology: 36.000,-Kč (each additional hour 19.000,-Kč) *** |
TECHNICAL SPECIFICATIONS
Main parameters
Brightness 800 cd/m² (Nit)
Colour temperature 6.500K
Viewing distance 3 m
Viewing angle 140°
Pixel Error < 0.0001
Lifetime at 50% brightness 100,000 h
Voltage/Frequency 86-264 V 50-60 Hz
Operating temperature -20°C / +50°C ± 10%
Refresh rate 3000 Hz
Grayscale 14-bit
Brightness control 256 steps
Degree of protection IP30
Cabinet angles -5°-2.5° 0° +2.5° +5°
Module
Dimension 250 mm x 250 mm
Resolution 96 x 96
Pixel pitch 2.6 mm
Density 147456 px/m²
Pixel configuration 1R1G1B
LED type SMD1515
Cabinet
Dimension 500 x 500 x83 mm
Weight 7.5 kg
Number of modules 4
Number of pixels 36864 (192 x 192)
Average power consumption 200 W/m²
Maximum power consumption 600 W/m²
Material Aluminium
